69347B

・Frequency range: 0.01 to 20 GHz (Optional frequency extension down to 0.1 Hz).

・CW mode Output: Twenty independent, presettable CW frequencies (F0 to F9 and M0 to M9).

・CW mode Accuracy: Same as internal or external 10 MHz time base.

・CW mode Internal time base stability: With aging; <2 x 10–8/day (<5 x 10–10/day with Option 16), With temperature; <2 x 10–8/°C over 0°C (<2 x 10–10/°C with Option 16).

・CW mode Resolution: 1 kHz (0.1 Hz with Option 11).

・Analog Sweep width: Independently selected from 1 MHz to full range continuous sweep.

・Analog Sweep Accuracy: The lesser of ±30 MHz or (±2 MHz widths) for sweep speeds of <=50 MHz/ms.

・Output power: +13 dBm (+11 dBm with attenuator) >= 0.01 to <= 20 GHz.

・Output power resolution: 0.01 dB (log) or 0.001 mV (linear).
